Brand：NTH
1.This is a compact, short form, light weight through-hole rotary cylinder.
2.The safety check valve and pressure relief valve are built in the cylinder.
3.Large feed port and drain port, large input and keep drain smoothly.
4.Can be screwed from the front end or rear end of cylinder when mounting.
5.For use with vertical or horizontal spindles.
尺寸單位：毫米 /Size Unite: mm
|
Model
|
Piston Area(cm2)
Push
|
Piston Area(cm2)
Pull
|
Max.Draw Bar
ForcePush Side/
Pull SideKN(kgf)
|
Piston
Stroke
mm
|
Max.Operating
Pressure
Mpa(kgf/cm2)
|
Max RPM
|
Ikg*m2
|
Weight
kg
|
總流量
Total
Leakage
L/min
|
|
HH-1246
|
105
|
93.9
|
38(3875) / 33(3365)
|
15
|
4.0(40.8)
|
7000
|
0.019
|
9.5
|
3
|
|
HH-1552
|
135.3
|
125
|
60(6118) / 56(5710)
|
20
|
4.0(40.8)
|
6200
|
0.052
|
11.5
|
3.9
|
|
Model
|
A I.D.
|
B
|
C
|
D
|
E(h7)
|
F
|
G1(max)
|
G1(min)
|
G2(max)
|
G2(min)
|
|
HH-1246
|
128
|
165
|
147
|
147
|
100
|
65
|
15
|
0
|
34
|
19
|
|
HH-1552
|
145
|
185
|
165
|
170
|
130
|
70
|
20
|
0
|
47
|
27
|
|
Model
|
H
|
J
|
K
|
L
|
L1
|
L2
|
M1
|
M2
|
M3
|
N1
|
N2
|
N3
|
|
H-1246
|
4
|
113.3
|
148.3
|
6-M10
|
M8
|
14
|
M55*2.0
|
25
|
13
|
M52*1.5
|
25
|
8
|
|
H-1552
|
4.5
|
127
|
166.5
|
12-M10
|
M8
|
14
|
M60*2.0
|
30
|
15
|
M58*1.5
|
30
|
8
|
|
Model
|
O1
|
O2
|
P
|
Q1
|
Q2
|
R
|
S
|
T
|
U1
|
U2
|
V1
|
V2
|
W1
|
W2
|
Z
|
|
HH-1246
|
50
|
46
|
109.3
|
9
|
32
|
50
|
50
|
116
|
59
|
62
|
61.5
|
M5
|
98
|
M5
|
5
|
|
HH-1552
|
55
|
53
|
121
|
9
|
32
|
56
|
50
|
128
|
65
|
67
|
70
|
M5
|
110
|
M5
|
5
|
Subject to technology changes without prior information
Non-standard requirements can be made
